產品介紹
【次世代 Wi-Fi 6：體驗 3000 Mbps 的極速效能】 Archer AX53 為您的家庭網絡帶來飛躍性的提升。具備高達 3000 Mbps 的雙頻網速（5 GHz 頻段 2402 Mbps 與 2.4 GHz 頻段 574 Mbps），不論是觀看 4K 高畫質串流影片還是極速下載大型檔案，都能確保過程順暢無阻。
【連接更多設備，延遲更低】 搭載先進的 OFDMA 技術，將網絡容量提升了 4 倍，容許更多設備同時傳輸數據而互不干擾。這顯著降低了遊戲中的延遲，並讓視訊聊天更加即時、反應更迅速，滿足現代多設備家庭的需求。
【全屋覆蓋：訊號強勁無死角】 具備 4 根高增益外部天線，配合 波束成形 (Beamforming) 技術，能精準偵測設備位置並強化訊號覆蓋範圍。這確保了強大且可靠的 Wi-Fi 訊號能延伸至家中的每個角落，消除收訊盲點。
【智能守護與節能技術】 內建 TP-Link HomeShield，提供專業級的安全防禦，抵禦最新的網絡威脅。此外，目標喚醒時間 (Target Wake Time) 技術能優化設備的通訊排程，有效降低連網設備的功耗，延長電池壽命。您更可以透過 Amazon Alexa 使用語音指令輕鬆管理路由器，享受智慧生活。
Product Description
[Next-Gen Wi-Fi 6: Experience 3000 Mbps Extreme Speed] The Archer AX53 brings a significant upgrade to your home network. Delivering speeds up to 3000 Mbps (2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz), it ensures smooth 4K streaming and lightning-fast downloads, making buffer screens a thing of the past.
[Connect More, Lag Less] Equipped with OFDMA technology, the AX53 increases network capacity by 4 times, allowing simultaneous data transmission to multiple devices. This drastically reduces latency, making your online gaming more responsive and your video calls clearer and more stable.
[Expanded Coverage with Reliable Connections] Four high-gain external antennas combined with Beamforming technology focus signal strength directly towards your devices. This provides expansive, reliable Wi-Fi coverage throughout your entire home, ensuring a strong connection even in distant rooms.
[Smart Security & Enhanced Efficiency] Protect your digital life with TP-Link HomeShield, featuring advanced security to defend against modern cyber threats. The Target Wake Time (TWT) feature helps your mobile and IoT devices communicate more efficiently, reducing power consumption and saving battery life. Plus, manage your network hands-free with Amazon Alexa voice compatibility.
產品規格
-
Wi-Fi 速度: AX3000 (5 GHz: 2402 Mbps; 2.4 GHz: 574 Mbps)
-
技術特點: Wi-Fi 6 (802.11ax), OFDMA, Beamforming
-
乙太網絡接口: 1× Gigabit WAN + 4× Gigabit LAN
-
安全防護: WPA3, TP-Link HomeShield
-
智能家居: 支援 Amazon Alexa 語音控制
-
節能技術: 支援 Target Wake Time (TWT)
|
WIRELESS
|
| Standards and Protocols |
Wi-Fi 6
IEEE 802.11ax/ac/n/a 5 GHz
IEEE 802.11ax/n/b/g 2.4 GHz |
| WiFi Speeds |
AX3000
5 GHz: 2402 Mbps (802.11ax, HE160)
2.4 GHz: 574 Mbps (802.11ax) |
| WiFi Range |
2-3 Bedroom Houses
4× Fixed High-Performance Antennas
Multiple antennas form a signal-boosting array to cover more directions and large areas
Beamforming
Concentrates wireless signal strength towards clients to expand WiFi range
High-Power FEM
Improves transmission power to strengthen signal coverage |
| WiFi Capacity |
High
Dual-Band
Allocate devices to different bands for optimal performance
OFDMA
Simultaneously communicates with multiple Wi-Fi 6 clients
Airtime Fairness
Improves network efficiency by limiting excessive occupation
DFS
Access an extra band to reduce congestion
4 Streams
Connect your devices to more bandwidth |
| Working Modes |
Router Mode
Access Point Mode |
|
SECURITY
|
| Network Security |
SPI Firewall
Access Control
IP & MAC Binding
Application Layer Gateway
HomeShield Security
Real-Time IoT Protection
Malicious Site Blocker
Intrusion Prevention System
DDoS Attack Prevention
Home Network Scanner |
| Guest Network |
1× 5 GHz Guest Network
1× 2.4 GHz Guest Network |
| VPN Server |
OpenVPN
PPTP VPN |
| WiFi Encryption |
WPA
WPA2
WPA3
WPA/WPA2-Enterprise |
|
HARDWARE
|
| Processor |
Dual-Core CPU |
| Ethernet Ports |
1× Gigabit WAN Port
4× Gigabit LAN Ports |
| Buttons |
Wi-Fi/WPS Button
Power On/Off Button
Reset Button |
| Power |
12 V ⎓ 2 A |
|
SOFTWARE
|
| Protocols |
IPv4
IPv6 |
| Service Kits |
HomeShield
Learn More>
|
| OneMesh™ |
OneMesh™ Supported
Without replacing your existing devices or buying a whole new WiFi ecosystem, OneMesh™ helps you create a more flexible network that covers your entire home with TP-Link OneMesh™ products.
Learn More>
All OneMesh Products>
|
| EasyMesh |
Mesh networking creates smooth, fast, stable roaming. Archer AX53 can flexibly build an EasyMesh network with EasyMesh-Compatible devices, which eliminates Wi-Fi dead zones, expand your network, and fill your entire home with high-speed Wi-Fi. Seamless Wi-Fi connections with one network name, one-click setting and flexible scalability.
Learn More>
|
| Parental Controls |
HomeShield Parental Controls
Custom Profiles
Professional Content Filter Library
Family Time
Bedtime
Off Time
Time Rewards
Family Online Time Ranking
Pause the Internet
Weekly and Monthly Reports |
| WAN Types |
Dynamic IP
Static IP
PPPoE
PPTP
L2TP |
| Quality of Service |
QoS by Device |
| Cloud Service |
Auto Firmware Upgrade
OTA Firmware Upgrade
TP-Link ID
DDNS |
| NAT Forwarding |
Port Forwarding
Port Triggering
DMZ
UPnP |
| IPTV |
IGMP Proxy
IGMP Snooping
Bridge
Tag VLAN |
| DHCP |
Address Reservation
DHCP Client List
Server |
| DDNS |
TP-Link
NO-IP
DynDNS |
| Management Features |
Tether App
Webpage
Check Web Emulator>
|
|
OTHER
|
| System Requirements |
Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
Cable or DSL Modem (if needed)
Subscription with an internet service provider (for internet access) |
| Certifications |
CE, RoHS |
| Environment |
Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Operating Humidity: 10%~90% non-condensing |
|
TEST DATA
|
| WiFi Transmission Power |
CE:
<20dBm (2.4GHz); <23dBm (5.15GHz~5.35GHz); <30dBm (5.47GHz~5.725GHz) |
| WiFi Reception Sensitivity |
2.4GHz:
11ac VHT20_MCS0:-96dBm
11ac VHT20_MCS8:-74dB
11ac VHT40_MCS0:-94dBm
11ac VHT40_MCS9:-70dB
11ax HE20_MCS0:-96dBm
11ax HE20_MCS11:-66dBm
11ax HE40_MCS0:-93dBm
11ax HE40_MCS11:-63dBm
5GHz:
11ac VHT20_MCS0:-97dBm
11ac VHT20_MCS8:-75dBm
11ac VHT40_MCS0:-94dBm
11ac VHT40_MCS9:-70dBm
11ac VHT80_MCS0:-91dBm
11ac VHT80_MCS9:-67dBm
11ac VHT160_MCS0:-88dBm
11ac VHT160_MCS9:-63dBm
11ax HE20_MCS0:-97dBm
11ax HE20_MCS11:-66dBm
11ax HE40_MCS0:-94dBm
11ax HE40_MCS11:-63dBm
11ax HE80_MCS0:-91dBm
11ax HE80_MCS11:-61dBm
11ax HE160_MCS0:-87dBm
11ax HE160_MCS11:-58dBm |
|
PHYSICAL
|
| Dimensions (W×D×H) |
10.2 × 5.3 × 1.6 in
(260.2 × 135 × 41.6 mm) |
| Package Content |
Wireless Router Archer AX53
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide |
