產品介紹
【WiFi 7 時代開啟：6.5 Gbps 極速無線體驗】 Archer BE400 為您的家庭網絡帶來全新的 WiFi 7 效能。具備高達 6.5 Gbps 的雙頻網速，不論是流暢播放 4K/8K 超高畫質影片、沉浸式的 AR/VR 遊戲，還是超大檔案的極速下載，都能輕鬆應付。讓您的連網設備發揮 100% 的潛力，告別網絡壅塞。
【MLO 多鏈路運作：突破性的傳輸技術】 搭載 WiFi 7 核心的 MLO (Multi-Link Operation) 技術，Archer BE400 能夠讓設備同時跨多個頻段傳輸數據。這不僅能大幅提升數據吞吐量，還能有效降低延遲並提升穩定性，確保您的網絡行為不論是辦公還是娛樂都更具韌性。
【雙 2.5G 端口：為高速光纖而生】 配備 1 個 2.5 Gbps WAN 端口 與 1 個 2.5 Gbps LAN 端口，完美適配超過 1000M 的高速光纖寬頻。搭配額外的 3 個 Gigabit LAN 端口，為您的電競主機、NAS 或智慧電視提供最穩定的高速有線連接。
【全方位覆蓋與安全防護】 具備 6 根高性能外部天線搭配波束成形 (Beamforming) 技術，大幅提升信號覆蓋範圍並減少干擾。支援 EasyMesh，可與其他設備組成無縫全屋網絡。內建 TP-Link HomeShield，提供進階安全防禦，保護您的私隱與智能設備免受網絡威脅。
Product Description
[The Era of WiFi 7: Blazing-Fast 6.5 Gbps Experience] The Archer BE400 brings the future of connectivity to your home with WiFi 7 performance. Delivering combined speeds of up to 6.5 Gbps, it ensures your devices run at full throttle. Experience fluid 4K/8K streaming, immersive AR/VR gaming, and lightning-fast downloads, effectively eliminating buffering for all your high-bandwidth activities.
[MLO Technology: Breaking Connectivity Barriers] Featuring Multi-Link Operation (MLO), the Archer BE400 allows devices to transmit data across multiple bands simultaneously. This revolutionary WiFi 7 capability increases overall throughput, slashes latency, and significantly improves reliability for a more stable and responsive networking experience.
[Dual 2.5G Wired Connections: Ready for High-Speed Fiber] Equipped with 1× 2.5 Gbps WAN port and 1× 2.5 Gbps LAN port, this router is designed to fully leverage multi-gigabit internet plans. Along with 3× Gigabit LAN ports, it provides high-speed data transmission for your gaming rigs, NAS systems, and workstations.
[Maximized Coverage & Robust Security] Six external high-performance antennas combined with Beamforming technology deliver expanded capacity and a stronger, more reliable signal throughout your home. EasyMesh-compatibility allows you to form a seamless Mesh network, while TP-Link HomeShield defends your family and devices against the latest cyber threats.
產品規格
-
WiFi 速度: BE6500 (5 GHz: 5760 Mbps; 2.4 GHz: 688 Mbps)
-
技術特點: WiFi 7, MLO, 4K-QAM, Multi-RU
-
乙太網絡接口:
-
1× 2.5 Gbps WAN
-
1× 2.5 Gbps LAN
-
3× 1 Gbps LAN
-
天線: 6× 高性能外部天線
-
管理方式: Tether App / Web UI
-
Mesh 技術: 支援 EasyMesh
|
WIRELESS
|
| WiFi Speeds |
BE6500
• 5 GHz: 5764 Mbps (802.11be)
• 2.4 GHz: 688 Mbps (802.11be) |
| WiFi Range |
3 Bedroom Houses
6× External Antennas
Multiple antennas form a signal-boosting array to cover more directions and large areas
Beamforming
Concentrates wireless signal strength towards clients to expand WiFi range |
| WiFi Capacity |
High
Dual-Band
Allocate devices to different bands for optimal performance
MU-MIMO
Simultaneously communicates with multiple MU-MIMO clients
OFDMA
Simultaneously communicates with multiple clients
Airtime Fairness
Improves network efficiency by limiting excessive occupation
DFS
Access an extra band to reduce congestion
4 Streams
Connect your devices to more bandwidth |
| Advanced Features |
• Multi-Link Operation (MLO)
• 4K-QAM
• Multi-RUs
• EasyMesh-Compatible
• Works with Alexa and Google Assistant
• IoT Network |
| Wireless Mode |
• Router Mode
• Access Point Mode |
|
SECURITY
|
| Network Security |
• SPI Firewall
• Access Control
• IP & MAC Binding
• Application Layer Gateway
• HomeShield Security
Real-Time IoT Protection
Malicious Site Blocker
Intrusion Prevention System
DDoS Attack Prevention
Home Network Scanner |
| Guest Network |
• 1× 5 GHz Guest Network
• 1× 2.4 GHz Guest Network |
| VPN Server |
• OpenVPN Server
• PPTP VPN Server
• L2TP VPN Server
• WireGuard VPN Server |
| VPN Client |
• Open VPN Client
• PPTP VPN Client
• L2TP VPN Client
• WireGuard VPN Client |
| WiFi Encryption |
• WPA
• WPA2
• WPA3
• WPA/WPA2-Enterprise (802.1x) |
|
HARDWARE
|
| Ethernet Ports |
• 1× 2.5 Gbps WAN
• 1× 2.5 Gbps LAN
• 3× 1 Gbps LAN |
| USB Support |
1× USB 3.0
• Supported Partition Formats:
NTFS, exFAT, HFS+, FAT32
• Supported Functions:
FTP Server
Media Server
Samba Server |
| Buttons |
• Power Button
• Wi-Fi/LED Button
• WPS Button
• Reset Button |
| Power |
12 V ⎓ 2.5 A |
|
SOFTWARE
|
| Protocol |
• IPv4
• IPv6 |
| Service Kit |
HomeShield
Learn More>
|
| EasyMesh |
Compatible with EasyMesh |
| Parental Controls |
HomeShield Parental Controls
Custom Profiles
Professional Content Filter Library
Family Time
Bedtime
Off Time
Time Rewards
Family Online Time Ranking
Pause the Internet
Weekly and Monthly Reports |
| WAN Type |
• Dynamic IP
• Static IP
• PPPoE
• PPTP
• L2TP |
| Quality of Service |
QoS by Device |
| Cloud Service |
• Auto Firmware Upgrade
• TP-Link ID
• DDNS |
| NAT Forwarding |
• Port Forwarding
• Port Triggering
• DMZ
• UPnP |
| IPTV |
• IGMP Proxy
• IGMP Snooping
• Bridge
• Tag VLAN |
| DHCP |
• Address Reservation
• DHCP Client List
• Server |
| DDNS |
• TP-Link
• NO-IP
• DynDNS |
| Management Features |
• Tether App
• Webpage |
|
OTHER
|
| Network Services Enabled by Default |
Web Server
Manage and configure device through web (HTTP/HTTPS)
• Port: 80/443 Protocol: TCP
DNS
DNS
• Port: 53 Protocol: TCP & UDP
DHCP Server
IP address assignment (DHCP)
• Port: 67 Protocol: UDP
App management
Manage and configure device through app
• Port: 20001 Protocol: TCP
• Port: 30001 Protocol: TCP
• Port: 20002 Protocol: UDP |
| System Requirements |
Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
Cable or DSL Modem (if needed)
Subscription with an internet service provider (for internet access) |
| Certifications |
CE, FCC, RoHS |
| Environment |
• Operating Temperature: 0℃~40℃ (32℉ ~104℉)
• Operating Humidity: 10%~90% non-condensing |
