【4K 頂級畫質：捕捉監控全局細節】
VIGI NVR1008H-8P 支援高達 8 頻道的即時預覽，並配備 4K HDMI 影像輸出，讓您在 4K 螢幕上清晰查看每一個角落。強大的解碼能力支援同時播放 8 路 2MP 或 4 路 4MP 影像，確保回放畫面順暢且細節分明。
【一線整合：內建 8 埠 PoE+ 專業供電】
告別複雜的佈線！主機內建 8 個 10/100 Mbps PoE+ 連接埠，具備 53W 總供電預算。只需透過一條網線，即可同時為攝影機傳輸數據與電力，無需額外安裝電源適配器，讓安裝過程更簡潔、更專業。
【海量儲存與高效壓縮技術】
具備 1 個 SATA 介面，支援最高 16TB 硬碟容量，為您的錄影提供長期穩定的儲存空間。採用專業級 H.265+ 視訊壓縮技術，在維持清晰畫質的同時，大幅節省硬碟空間並降低網絡頻寬壓力，實現更長的錄影存留時間。
【雙介面輸出與靈活遠端管理】
支援 HDMI 與 VGA 同步輸出，適配各種顯示設備。透過 VIGI App 或專用管理軟體，無論您身在何處，都能透過手機或電腦進行遠端監控、即時查看畫面並接收警報通知，讓您的安全防護如影隨行。
[4K Ultra-HD Monitoring: Every Detail Counts]
The VIGI NVR1008H-8P supports up to 8 channels of live view and features a stunning 4K HDMI video output. Whether monitoring a storefront or a warehouse, the crystal-clear display ensures no detail is missed. With strong decoding capabilities, it can handle up to 8-ch @ 2MP or 4-ch @ 4MP synchronous playback effortlessly.
[Seamless Setup: Integrated 8-Port PoE+]
Simplify your security infrastructure. This NVR comes with 8 built-in 10/100 Mbps PoE+ ports with a 53W power budget. A single Ethernet cable handles both data and power for each connected camera, eliminating the need for extra power adapters and reducing installation complexity.
[Extensive Storage & Smart Compression]
Equipped with a SATA interface supporting up to 16TB, providing massive capacity for high-definition video archives. Utilizing H.265+ compression, the system transmits crystal-clear video while saving significant disk space and lowering network costs without sacrificing image quality.
[Dual Output & Remote Accessibility]
Featuring simultaneous HDMI and VGA outputs for flexible display options. Stay connected 24/7 with Remote Monitoring via the VIGI app or Security Manager. Access live feeds, playback recordings, and receive instant notifications on your smartphone or PC from anywhere in the world.
| 類別 (Category) | 繁體中文 (Traditional Chinese) | 英文 (English) |
| 品牌 (Brand) | TP-Link / VIGI | TP-Link / VIGI |
| 頻道 (Channel) | 8 頻道 / 8路監控 | 8-Channel / 8-Ch NVR |
| 技術 (Tech) | PoE+ 供電 / H.265+ | PoE+ Powered / H.265+ |
| 輸出 (Output) | 4K HDMI / 雙介面輸出 | 4K HDMI / Dual Output |
| 儲存 (Storage) | 16TB 支援 / SATA 介面 | 16TB Support / SATA |
| Video and Audio | |
|---|---|
| IP Video Input | 8-Channel |
| Incoming Bandwidth | 80 Mbps |
| Outgoing Bandwidth | 60 Mbps |
| HDMI Output Resolution | 1 Channel, Resolution: 3840x2160/30Hz, 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz |
| VGA Output Resolution | 1 Channel, Resolution: 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz |
| Video Output Mode | HDMI/VGA Simultaneous Output |
| Multi-View Display | 1/4/6/8 |
| DECODING | |
|---|---|
| Audio Compression | G.711A/G.711U/G.726 |
| Decoding Format | H.265+/H.265/ H.264+/H.264 |
| Video Compression | H.265+/H.265/ H.264+/H.264 |
| Record Resolution | 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Live View/Playback Resolution | 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/ DCIF/2CIF/CIF/QCIF |
| Synchronous Playback | 8-Channel† |
| Capability | • 25fps: 2-ch @ 8MP, 4-ch @ 4MP, 8-ch @ 2MP • 30fps: 4-ch @ 3MP, 2-ch @ 5MP |
| Record Management | |
|---|---|
| Record Mode | Manual Recording, Scheduling Recording, Motion Detection Recording |
| Playback Mode | Instant Playback, Regular Playback, Tag Playback, Event Playback |
| Backup Mode | Regular Backup, Video Clip Backup |
| Playback Function | Play, Pause, Stop, Fast Forward, Fast Backward, Play By Frame, Full Screen, Video Clip, Export Clip, Digital Zoom, Lock Recording, Audio On/Off |
| NETWORK | |
|---|---|
| Protocol | UPnP (Plug and Play), NTP (Network Timing) |
| Mobile Phone Access | Android, iOS |
| Incoming Bandwith | 80 Mbps |
| Outgoing Bandwidth | 60 Mbps |
| Web Browser | Chrome (57+), Firefox (52+), Edge (91+) |
| Interoperability | ONVIF Profile S/T, CGI |
| External Interface | |
|---|---|
| Network Interface | 1 RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface |
| USB Interface | 2× USB 2.0 |
| Audio Interface | 1-ch RCA Input; 1-ch RCA Output |
| Alarm In/Out | N/A |
| Serial Interface | N/A |
| Power | 1× DC Jack |
| Reset Button | 1 |
| Speaker | N/A |
| eSATA | N/A |
| HDMI | 1 |
| VGA | 1 |
| HARD DISK | |
|---|---|
| SATA | 1 SATA Interface |
| Capacity | Up to 16 TB Capacity for Each HDD* |
| PoE | |
|---|---|
| Standard | 802.3at/af Compliant |
| Interface | 1- 8, RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface |
| PoE Budget | 53 W△ Available for All PoE+ Ports, 30 W Max per Port |
| Alarm | |
|---|---|
| General Alarm | • Motion Detection • Video Tampering • Scene Change Detection • Line-Crossing Detection • Intrusion Detection • Region Entering Detection • Region Exiting Detection • Loitering Detection • Object Abandoned/Removal Detection • Vehicle Detection • Human Detection • Abnormal Sound Detection • Smart Frame Note: The alarm function requires the use of a camera. |
| Anomaly Alarm | • Video Loss • Offline and IP Conflict • Disk Exception • Login Exception Note: The alarm function requires the use of a camera. |
| Alarm Linkage | • Recording • White Light Alarm • Buzzer • Log • Audible Alarm Note: The alarm function requires the use of a camera. |
| INTERFACES | |
|---|---|
| Network Interface | 1 RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface |
| USB Interface | 2× USB 2.0 |
| GENERAL | |
|---|---|
| Operating Temperature | -10–55 °C |
| Storage Temperature | -40–70 °C |
| Storage Humidity | 10%~90% RH Non-Condensing |
| Package Content | • VIGI Network Video Recorder • Power Adapter • HDD Screws • Mouse • Mounting Brackets & Rubber Feet • Quick Installation Guide |
| Working Temperature | NVR: -10–55 °C Power Adapter: 0–40 °C |
| Working Humidity | 10%~90% RH Non-Condensing |
| Dimensions( W X D X H ) | 294 × 180 × 44 mm |
| PoE | Standard: 802.3af/at PoE Ports: Ports 1-8 PoE Budget: 53 W |
| External Power Supply | 53.5V DC/1.31 A |
| Net Weight | 1.12 Kg |
| Gross Weight | 2.06 Kg |
| Power Supply | 53.5V DC/1.31A |
| Max. Power Consumption | 2.38 W (without disk) 12.94 W (with disk) |
| Certifications | CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC, HDMI |
| VIDEO/IMAGE | |
|---|---|
| Video Input | 8-Channel IP Video Input, up to 8 MP Resolution |
| Recording Resolution | 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF |
| HDMI Output Resolution | 1 Channel, Resolution: 3840x2160/30Hz,1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1024x768/60Hz, 1280x720/60Hz |
| VGA Output Resolution | 1 Channel, Resolution: 1920x1080/60Hz,1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz, |
