產品介紹
【WiFi 7 效能巔峰：9.3 Gbps 三頻極速體驗】
Deco BE65 引領您的家居網絡進入 WiFi 7 新紀元。憑藉 9.3 Gbps 的強大三頻輸出，結合全新的 6GHz 頻段與 320 MHz 超闊頻寬，數據傳輸容量翻倍。不論是 8K 超高畫質串流、大規模雲端下載還是即時 VR 互動，都能提供如絲般順滑的連線體驗。
【全 2.5 Gbps 有線連接：解放光纖潛能】
為了配合現代高速光纖寬頻，Deco BE65 每台節點均配備了 4 個 2.5 Gbps 端口。這意味著您不僅能享受極速的無線網絡，連 NAS 儲存伺服器、電競 PC 或遊戲主機都能透過有線連接獲得滿血性能，徹底告別千兆網口的瓶頸。
【MLO 技術與混合回傳：極致穩定的 Mesh 網絡】
搭載 多鏈路操作 (MLO) 技術，Deco BE65 容許設備同時連接多個頻段，顯著降低延遲並提升穩定性。系統更支援「無線 + 有線」混合回傳（Combined Backhaul），讓不同房間之間的網絡銜接更緊密，實現全屋無死角的無縫漫遊。
【TP-Link HomeShield：專業級家庭網絡防護】
安全無憂的上網環境。內建 HomeShield 技術提供實時 IoT 設備監控、惡意網站攔截及功能強大的家長控制。您可以輕鬆過濾不良資訊並管理家人的上網時間，透過 Deco App 即可掌握一切。
Product Description
[WiFi 7 Excellence: 9.3 Gbps Tri-Band Speed]
Step into the future with the Deco BE65, a premium WiFi 7 Mesh system designed for the ultimate home network. Delivering a combined speed of 9.3 Gbps across three bands, it utilizes the new 6GHz spectrum and 320 MHz channels to double your bandwidth. Experience lag-free 8K streaming, rapid cloud transfers, and immersive gaming like never before.
[Full 2.5 Gbps Wired Connectivity]
To complement modern high-speed fiber services, each Deco BE65 unit is equipped with four 2.5 Gbps ports. This ensures total flexibility for your high-performance wired devices, such as NAS systems, gaming consoles, or workstations, allowing you to maximize every megabit of your internet plan.
[MLO & Combined Backhaul: Rock-Solid Mesh Stability]
With Multi-Link Operation (MLO), the system enables devices to send and receive data across different bands simultaneously, drastically reducing latency. By combining wireless and wired backhauls, the Deco BE65 creates a unified, high-throughput network that keeps you connected seamlessly as you move throughout your home.
[TP-Link HomeShield: Smart Security for the Modern Home]
Protect your digital life with TP-Link HomeShield. It provides real-time IoT protection, robust parental controls, and comprehensive network security scans. Easily manage online time limits and block inappropriate content for a safer, healthier internet experience for the whole family.
產品規格
-
WiFi 速度: BE9300 (6 GHz: 5765 Mbps; 5 GHz: 2882 Mbps; 2.4 GHz: 688 Mbps)
-
技術標準: WiFi 7 (802.11be), MLO, 320MHz Channel, 4K-QAM
-
乙太網絡接口: 每部節點備有 4× 2.5 Gbps WAN/LAN 端口
-
天線: 高增益內置天線，支援波束成形 (Beamforming)
-
安全性: WPA3, TP-Link HomeShield, IoT 安全防護
-
相容性: 向後相容所有舊有 WiFi 世代及任何 ISP 適配器
| 類別 (Category) |
繁體中文 (Traditional Chinese) |
英文 (English) |
| 品牌 (Brand) |
TP-Link |
TP-Link |
| 系列 (Series) |
Deco / Mesh WiFi |
Deco / Mesh WiFi |
| 技術 (Tech) |
WiFi 7 / 三頻 |
WiFi 7 / Tri-Band |
| 端口 (Port) |
2.5G 端口 / 滿血版 |
2.5G Port / High-Speed |
| 功能 (Features) |
HomeShield / 無縫漫遊 |
HomeShield / Seamless Roaming |
|
WIRELESS
|
| Standards and Protocols |
Wi-Fi 7
IEEE 802.11be/ax 6 GHz
IEEE 802.11be/ax/ac/n/a 5 GHz
IEEE 802.11be/ax/n/b/g 2.4 GHz |
| WiFi Speeds |
BE9300
6 GHz: 5765 Mbps (802.11be)
5 GHz: 2882 Mbps (802.11be)
2.4 GHz: 688 Mbps (802.11be) |
| WiFi Range |
Broader Whole Home Coverage
TP-Link Mesh Technology
Optional Ethernet backhaul work together to link Deco units to provide seamless coverage
AI-Driven Mesh
Intelligently learns the network environment to provide ideal Wi-Fi unique to your home
4× High-Performance Antennas (Internal)
Multiple antennas form a signal-boosting array to cover more directions and large areas
Tri-Band
A newly-opened 6 GHz band brings more bandwidth and faster speeds |
| WiFi Capacity |
Very High
Tri-Band
Distribute devices to different bands for optimal performance
2×2 MU-MIMO
Simultaneously communicates with multiple MU-MIMO clients
OFDMA
Simultaneously communicates with multiple WiFi 7 clients
6 Streams
More than enough bandwidth for connected devices |
| Working Modes |
Router Mode
Access Point Mode |
| Advanced Features |
• Multi-Link Operation (MLO)
• 320 MHz Channel
• 4K-QAM
• Multi-RUs
• Works with Alexa and Google Assistant |
|
SECURITY
|
| Network Security |
SPI Firewall
Access Control
HomeShield Security
Real-Time IoT Protection
Malicious Site Blocker
Intrusion Prevention System
DDoS Attack Prevention
Home Network Scanner |
| Guest Network |
1× 6 GHz Guest Network
1× 5 GHz Guest Network
1× 2.4 GHz Guest Network
Effective Time
Bandwidth Control |
| VPN Server |
• OpenVPN Server
• PPTP VPN Server
• L2TP/IPSec VPN Server |
| VPN Client |
• OpenVPN Client
• PPTP VPN Client
• L2TP/IPSec VPN Client |
| WiFi Encryption |
WPA-Personal
WPA2-Personal
WPA3-Personal |
|
HARDWARE
|
| Ethernet Ports |
• 4× 2.5 Gbps
*Per Deco Unit
Supports WAN/LAN auto-sensing |
| USB Support |
1× USB 3.0 Port
FTP Server
Media Server
Samba Server |
| Buttons |
1× Reset Button
1× WPS |
|
SOFTWARE
|
| Advanced Features |
• Reboot Schedule
• Tapo/Kasa Onboarding
• IoT network & Device Isolation
• Static Routing Function
• Node/Band Connection Preference |
| Protocols |
IPv4
IPv6 |
| Service Kits |
HomeShield
Learn More>
|
| Parental Controls |
HomeShield Parental Controls
Youtube Restriction
SafeSearch
Custom Profiles
Professional Content Filter Library
Family Time
Bedtime
Off Time
Time Rewards
Family Online Time Ranking
Pause the Internet
Weekly and Monthly Reports |
| WAN Types |
Dynamic IP
Static IP
PPPoE
PPTP
L2TP |
| Quality of Service |
HomeShield QoS
QoS by Device |
| Cloud Service |
OTA Firmware Upgrade
TP-Link ID
DDNS |
| NAT Forwarding |
Port Forwarding
UPnP |
| IPTV |
IGMP Proxy
IGMP Snooping
Bridge
Tag VLAN |
| DHCP |
Address Reservation
DHCP Client List
Server |
| DDNS |
TP-Link |
| Management Features |
Deco App |
|
OTHER
|
| Network Services Enabled by Default |
Web Server
Manage and configure device through web (HTTP/HTTPS)
• Port: 80/443 Protocol: TCP
DNS
DNS
• Port: 53 Protocol: TCP & UDP
DHCP Server
IP address assignment (DHCP)
• Port: 67 Protocol: UDP
App management
Manage and configure device through app
• Port: 22 Protocol: TCP
• Port: 20001 Protocol: TCP
• Port: 30001 Protocol: TCP
• Port: 20002 Protocol: UDP |
|
PHYSICAL
|
| Dimensions (W×D×H) |
4.23 × 4.23 × 6.93 in (107.5 × 107.5 × 176 mm) |
| Package Content |
Deco BE65 (3-pack)
3 Deco BE65 units
1 RJ45 Ethernet cable
3 Power adapters
Quick Installation Guide
Deco BE65 (2-pack)
2 Deco BE65 units
1 RJ45 Ethernet cable
2 Power adapters
Quick Installation Guide
Deco BE65 (1-pack)
1 Deco BE65 unit
1 RJ45 Ethernet cable
1 Power adapter
Quick Installation Guide |
|
OTHERS
|
| Certifications |
CE, FCC, RoHS |
| Environment |
Operating Temperature: 0°C~40°C (32 °F~104 °F)
Storage Temperature: -40°C~60°C (-40 °F~140 °F)
Operating Humidity: 10%~90% RH
Storage Humidity: 5%~90% RH |
